Specifications
Processor: AMD Geode GX 366MHz
Memory: 64MB Flash/128MB RAM
I/O peripheral support: VGA-type video output
Enhanced USB keyboard with PS/2 mouse port and Windows keys
PS/2 mouse included
One serial port
Four USB 2.0 ports (2 on front, 2 on back)
Networking: 10/100 Base-T Fast Ethernet twisted pair (RJ-45)
Display: 16 bpp color: up to 1600x1200@85Hz
32 bpp color: up to 1680x1050@60Hz
Audio: Output: 1/8-inch mini jack, full 16 bit stereo, 48KHz sample rate
Input: 1/8-inch mini jack, 8 bit microphone
Physical characteristics: Height: 1.38" (34mm)
Width: 6.94" (177mm)
Depth: 4.75" (121mm)
Shipping Weight: 6 lbs. (2.7kg)
Mountings: Horizontal feet (optional vertical stand)
Optional VESA mounting bracket
Built-in Kensington security slot (cable sold separately)
Power: Worldwide auto-sensing 100-240 VAC, 50/60 Hz
Average power usage with device connected to 1 keyboard with 1 PS/2 mouse and 1 monitor: 6.6 Watts
Temperature Range: Horizontal and Vertical positions: 50° to 104° F (10° to 40° C)
Humidity 20% to 80% noncondensing
Safety Certifications: German EKI-ITB 2000, ISO 9241-3/-8
cULus 60950, TÜV-GS, EN 60950
FCC Class B, CE, VCCI, C-Tick
WEEE, RoHS Compliant
Warranty: Three-year limited warranty
