Download DatasheetSpecifications
Processor: VIA 1GHz
Chipset: VIA VX855
Memory: 128MB Flash / 512MB RAM DDR2
I/O peripheral support: One DVI-port, DVI to VGA (DB-15) adapter included
Dual-video Support with optional DVI-I to DVI-D plus VGA-monitor splitter cable (sold separately)
Four USB 2.0 ports (2 on front, 2 on back)
Two PS/2 ports
One Mic In
One Line Out
Enhanced PS/2 Keyboard with Windows Keys (104 keys)
PS/2 Optical mouse included
Networking: 10/100/1000 Base-T Gigabit Ethernet
Internal 802.11 b/g/n (optional) eliminates theft of external wireless adapters
Display: VESA monitor support with Display Data Control (DDC) for automatic setting of resolution and refresh rate
Dual monitor supported
Single: 1920x1200x32@60Hz, Color depth: 8, 15, 16, 24 or 32bpp,
Two independent full resolution frame buffers
Dual: 1920x1200x32@60Hz, Color Depth: 8, 15, 16, 24 or 32bpp
Audio: Output: 1/8-inch mini jack, full 16 bit stereo, 48KHz sample rate
Input: 1/8-inch mini jack, 8 bit microphone
Physical characteristics: Height: 1.38 inches (34mm)
Width: 6.94 inches (177mm)
Depth: 4.75 inches (121mm)
Shipping Weight: 6 lbs. (2.7kg)
Mountings: Horizontal feet (optional vertical stand)
Optional VESA mounting bracket
Device Security: Built-in Kensington security slot (cable sold separately)
Power: Worldwide auto-sensing 100-240 VAC, 50/60 Hz. Energy Star V.5.0 compliant power supply
Average power usage with device connected to 1 keyboard with 1 PS/2 mouse and 1 monitor: Under 10 Watts
Temperature Range: Horizontal and Vertical positions: 50° to 104° F (10° to 40° C)
Humidity: 20% to 80% condensing 10% to 95% non-condensing
Safety Certifications: German EKI-ITB 2000, ISO 9241-3/-8
cULus 60950, TÜV-GS, EN 60950
FCC Class B, CE, VCCI, C-Tick
WEEE, RoHS Compliant
Warranty: Three-year hardware warranty
